Infrared and electrical safety: meeting safety requirements using IR windows and thermal imaging

BY COLIN PLASTOW, FLUKE Electronics

By installing IR (infrared) windows, panes or ports, technicians using thermal imagers can inspect live electrical equipment without removing protective covers. Unlike a port or pane, the additional protection afforded by infrared (IR) windows comes from their crystal optic construction, which is designed to better protect technicians under fault conditions resulting from unexpected component failures or work on other parts of the system. This substantially reduces hazard ratings and, in most cases, allows the thermographer to work more safely, minimizing the need...

Absence of voltage testing is a vital step in the process of verifying and establishing a de-energized state of any electrical system. As detailed in NFPA 70E clause 4.2.5., there is a specific and approved approach to establishing an electrical safe work condition with the following steps:

• determine all possible source of electrical supply
• interrupt the load current, open the disconnecting device for each possible source
• verify where possible that all blades of the disconnecting devices are open
• release or block any stored energy
• apply lockout device in accordance with documented and established work procedures
• using an adequately rated portable...
